Power over Ethernet

802.3af

Resolution

2MP

Protection class

IP66

Camera class

Standard Hikvision

Technology and conveniences

AcuSense, Deep Learning, Vehicle detection

WDR

True WDR (120 dB) - Darkfighter

Zoom (optical)

4x

Zoom (digital)

16x

Lens type

Varifocal - motorized

Lens [mm]

2,8 to 12 (adjustable)

Illumination

IR

Illumination range [m]

20

Purpose

Outdoor

Slot for Memory Card

microSD - up to 512GB

Max. resolution [pixels]

1920 x 1080 (Full HD)

Audio

1 input, 1 output, Microphone

Viewing Angle [°]

30 up to 100

Day/night mode

IR cut filter

Antivandal (Impact protection)

IK10

Number of streams

2

Power type

PoE, DC terminal

LAN speed

(1) 10/100Mbps

Max. power consumption [W]

9,2

Power via connector/terminal

12V DC

Video compression

H.264, H.265, MJPEG

Operating temperature [°C]

-20 up to 60

Weight [g]

560

Depth [mm]

131

Width [mm]

131

Height [mm]

104

Color

White

Minimum illumination [Lux]

0,005

Image sensor ["]

1/2.8

Default IP address

192.168.1.64

Pan and Tilt

Pan: 0° ~ 355°; Tilt: 0° ~ 90°

Default login and password

admin / -

Speed of Pan and Tilt

0.1° ~ 50°/s
