TP-Link Archer NX505, 5G Wi-Fi 6 router
Your price incl. VAT (20.0%)
255.10 EUR
❌ The item is not available. There is no option to order.
No confirmed delivery date
Product description
TP-Link Archer NX505 is a 5G dual-band Wi-Fi 6 router operating simultaneously on the 2.4GHz and 5GHz bands to deliver a maximum throughput of up to 3Gbps. It is equipped with (3) 1G ports (1x LAN/WAN, 2x LAN), (2) TS-9 female connectors for external 5G antennas, (1) nano SIM slot and WAN failover.
The router is equipped with a modem supporting 5G, 4G and 3G, with data rates of up to 6470Mbps downlink and 1250Mbps uplink, and is compatible with EasyMesh.
Package contents
- Device
- Patch cable
- Power adapter 12V/2.5A
Download
Technical parameters
LAN ports
Design
Desktop
Maximum modulation
1024 QAM
Max. WAN speed
1G
Technology and conveniences
EasyMesh
Operating mode
AP Router
Wireless frequency
2.4 + 5 GHz (dual band), 5G (GSM), LTE, 4G (GSM)
WiFi standards
802.11a, 802.11ac, 802.11ax, 802.11b/g, 802.11n
MU-MIMO
Yes
Transmission speed - 5GHz [Mb/s]
2402
Transmission speed - 2.4GHz [Mb/s]
574
Security
WPA, WPA2, WPA3
2.4GHz MIMO
2 x 2
5GHz MIMO
2 x 2
Type of antenna
Built-in, Detachable
Detachable antennas
2
RF connectors
(2) TS-9 female
Purpose
Indoor
Integrated 4G/LTE radio part
Yes
4G/LTE bands support
(1) 2100 MHz, (20) 800 MHz, (28) 700 MHz, (3) 1800 MHz, (32) 1500 MHz, (38) 2600 MHz, (40) 2300 MHz, (41) 2500 MHz, (42) 3500 MHz, (43) 3700 MHz, (5) 850 MHz, (7) 2600 MHz, (71) 600 MHz, (8) 900 MHz
5G bands support
(n1) 2100 MHz, (n20) 800 MHz, (n28) 700 MHz, (n3) 1800 MHz, (n38) 2600 MHz, (n40) 2300 MHz, (n41) 2500 MHz, (n5) 850 MHz, (n7) 2600 MHz, (n71) 600 MHz, (n75) 1500 MHz, (n76) 1500 MHz, (n77) 3700 MHz, (n78) 3500 MHz, (n8) 900 MHz
LAN speed
(2) 10/100/1000Mbps + (1) 10/100/1000Mbps LAN/WAN
LAN ports 1G
3
Gigabit LAN
Yes
Power via connector/terminal
12V / 2,5A
Buttons
Reset, WPS/WiFi
Operating temperature [°C]
0 up to 40
Width [mm]
99
Height [mm]
190
Depth [mm]
99
SIM slot
Yes
SIM slots quantity
1
IPv6 support
Yes
Default IP address
192.168.1.1
Default login and password
Is set by the user at the first startup
