Power over Ethernet

9 .. 30V DC

Design

Industry

Max. WAN speed

100M

Operating mode

AP Router, Cellular router

Wireless frequency

2.4 GHz, LTE, 3G (GSM)

WiFi standards

802.11b/g, 802.11n

Transmission speed - 2.4GHz [Mb/s]

150

Security

WPA, WPA2, WPA3, OWE

2.4GHz MIMO

1 x 1 SISO

Type of antenna

Detachable

Detachable antennas

3

RF connectors

(2) SMA female, (1) RP-SMA female

Integrated 4G/LTE radio part

Yes

Power type

4-pin automotive, PoE

4G/LTE bands support

(1) 2100 MHz, (20) 800 MHz, (28) 700 MHz, (3) 1800 MHz, (32) 1500 MHz, (38) 2600 MHz, (40) 2300 MHz, (41) 2500 MHz, (5) 850 MHz, (7) 2600 MHz, (8) 900 MHz

Operating system

RutOS (OpenWrt based Linux OS)

LAN speed

(2) 10/100Mbps

LAN ports 100M

2

PoE type

PoE-In (only)

Max. power consumption [W]

3,5

Power via connector/terminal

9 .. 30V DC

Buttons

Reset

Operating temperature [°C]

-40 up to 75

Weight [g]

132

Width [mm]

83

Height [mm]

25

Depth [mm]

74

CPU frequency [MHz]

580

SIM slot

Yes

SIM slots quantity

1

IPv6 support

Yes

Default IP address

192.168.1.1

Internal storage [MB]

32

RAM [MB]

128

Default login and password

admin / (preset password, see label/engraving)
