USB ports 3.0

4

Design

Rackmount

Number of eSata ports

1

Number of Sata connectors

16

VGA connector

Yes

Camera class

Profi Hikvision

Number of supported IP cameras

128

Number of supported HDD

16

Supported HDD capacity [TB]

20

Raid level

0 - striping, 6 - striping, 5 - striping, 1 - mirroring, 10 - mirroring

HDMI interface (resolution) [pixels]

4096 x 2160 (4K UHD)

DP interface (resolution) [pixels]

7680 x 4320 (8K)

Audio

Yes

Alarm

Yes

"U" positions

3

LAN speed

(4) 10/100/1000/2500Mbps

Redundant power supply

Yes

Max. power consumption [W]

75

Serial port

RS-232, RS-485

Incoming bandwidth [Mb/s]

1024

Outgoing bandwidth [Mb/s]

1024

USB ports 2.0

2

Power via connector/terminal

230V AC

Video compression

H.264, H.265

Operating temperature [°C]

0 up to 50

Weight [g]

25000

Width [mm]

447

Height [mm]

133

Depth [mm]

490

Max. recording resolution

32MP

HDMI interface

Yes

DP interface

Yes
