Power over Ethernet

802.3at

Resolution

2MP

Protection class

IP67

Bit rate

32Kbps ~ 16Mbps

Camera class

Profi Hikvision

Technology and conveniences

Face capture, Deep Learning, Vehicle detection, Autotracking

WDR

True WDR (120 dB) - Darkfighter

Zoom (optical)

15x

Zoom (digital)

16x

Lens type

Varifocal - motorized

Lens [mm]

4,8 to 72 (adjustable)

Illumination

IR with strobe light

Illumination range [m]

100

Purpose

Outdoor

Slot for Memory Card

microSD - up to 512GB

Max. resolution [pixels]

1920 x 1080 (Full HD)

Audio

1 input, 1 output, 2 Microphones, speaker

Viewing Angle [°]

4 up to 57,6

Day/night mode

IR cut filter

Alarm

Yes

Number of streams

3

Power type

PoE, DC terminal

Heating

Yes

LAN speed

(1) 10/100Mbps

Max. power consumption [W]

18

Power via connector/terminal

12V DC

Video compression

MJPEG, H.264, H.265

Operating temperature [°C]

-30 up to 65

Weight [g]

2000

Height [mm]

290

Depth [mm]

165

Width [mm]

165

Color

White

Minimum illumination [Lux]

0,005

Image sensor ["]

1/2.8

Default IP address

192.168.1.64

Default login and password

admin / -

Pan and Tilt

Pan: 360° endless; Tilt: -15° ~ 90° (Auto Flip)

Speed of Pan and Tilt

0.1° ~ 80°/s
