Design

Rackmount

Switchning capacity [Gbps]

56

MAC address table

8000

Jumbo frame [Bytes]

10000

Packet forwarding rate [Mpps]

41,7

Web management

Yes

Management

Web management, SSH, Telnet, Wi-Tek Cloud, Mobilní aplikace

Features

VLAN, QoS, DHCP snooping, L2+

Power type

Mains power (230V)

Fans

Yes

LAN ports

24

LAN speed

(24) 10/100/1000Mbps

Max. LAN ports speed

1G

PoE type

PoE-Out (only)

SFP cages

4

Optical interfaces

(2) 1000Mbps + (2) 1000Mbps Combo

PoE-Out standards

802.3at, 802.3af

PoE Out ports

24

PoE budget [W]

370

Max. power consumption [W]

397

Serial port

RJ45

Buttons

Reset

Operating temperature [°C]

-10 up to 50

Weight [g]

2550

Width [mm]

442

Height [mm]

44

Depth [mm]

209

Default IP address

192.168.0.1

Default login and password

admin / admin
