Ubiquiti UMR-Ultra LTE router

Ubiquiti UMR-Ultra LTE router
Your price incl. VAT (20.0%)
96.88 EUR
Ordered for stock
Delivery Planned Delivery Date by Courier to you 10-09-2025
Ubiquiti
Manufacturer
Product number
UMR-Ultra
Product Code
RL028.719
Warranty
24 months

Product description

UniFi Mobile Router is a compact device with wide power options, two LAN ports, WiFi and LTE Cat4 modem.

One of the pair of gigabit ethernets also supports the PoE-out function. Power options are via a USB-C connector or a 4-pin connector. The router can be mounted directly on the wall with the included bracket or on a DIN rail using an additional intermediate piece, which is also included in the package. You can connect wirelessly at a frequency 2.4GHz with a maximum line speed 150Mbps. The LTE modem reaches category 4, which means speeds up to 150/50Mbps. You connect to the mobile operator's network using your own nanoSIM.

GPS and WiFi antennas are integrated inside the router, LTE antennas are detachable, the SIM slot is hidden under the antennas. The maximum consumption of the device itself is 5.7W.

Unit central management

UniFi APs doesn't have own web GUI and you manage them via UniFi Controller, which you can download on UBNT websites here: http://www.ubnt.com. Or you can manage UAP devices using UniFi Cloud Key which has UniFi Controller preinstalled. Additional benefit is fact that UniFi Controller software is free of costs and includes advanced functions without limitations.

UMR-Ultra

General advantages of UniFi products

  • Zero Handoff Roaming
  • Wireless uplink
  • Up to 8 SSID
  • Detailed traffic stats
  • Guest network
  • Load balance
  • Speed limitaions for each SSID

Package contains

  • Device
  • DIN rail
  • Wall mount bracket
  • DIN mount bracket
  • (4) Screws and anchors
  • LTE antennas

Download

https://dl.ui.com/qig/umr-ultra/#index
Download QSG
https://techspecs.ui.com/unifi/integrations/umr-ultra-us#datasheet
Download Datasheet

Technical parameters

LAN ports
Design
DIN rail, On the wall
Operating mode
Cellular router
WiFi standards
802.11b/g, 802.11n
Transmission speed - 2.4GHz [Mb/s]
150
Tx power 2.4GHz [dBm]
17
Type of antenna
Detachable
Detachable antennas
3
Integrated 4G/LTE radio part
Yes
4G/LTE bands support
(12) 700 MHz, (13) 700 MHz, (2) 1900 MHz, (25) 1900 MHz, (26) 850 MHz, (4) 1700 MHz, (5) 850 MHz, (66) 1700 MHz, (71) 600 MHz, (14) 700 MHz
LAN ports
2
LAN speed
(2) 10/100Mbps
Max. power consumption [W]
6
Power via connector/terminal
9 .. 30V DC
Buttons
Reset
Operating temperature [°C]
-30 up to 70
Width [mm]
82
Height [mm]
194
Depth [mm]
26
SIM slot
Yes
SIM slots quantity
1
