Grandstream GWN7811P Layer 3 Managed Network PoE Switch 8 ports / 2 SFP+
Your price incl. VAT (20.0%)
213.76 EUR
❌ The item is not available. There is no option to order.
No confirmed delivery date
10.59 EUR excl. VAT
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1330/Rx1270nm, 10KM, 1x LC connector, DDMML-S+3327-10
13.78 EUR excl. VAT
371.36 EUR excl. VAT
224.83 EUR excl. VAT
132.83 EUR excl. VAT
6.36 EUR excl. VAT
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1270/Rx1330nm, 10km, 1x LC connector, DDMML-S+2733-10
13.78 EUR excl. VAT
Product description
The GWN7810 series are Layer 3 managed network switches that allow enterprises to build scalable, secure, and high-performance business networks that are fully manageable.
Key features
- 8 Gigabit Ethernet ports and 2 10Gigabit SFP+ ports
- Smart power control to support dynamic PoE/PoE+ power allocation per port for the PoE models, Ports 1-8 on the GWN7813P support PoE++
- Supports deployment in IPv6 and IPv4 networks
- ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
- Embedded controller to manage switch; GWN Cloud and GWN Manager, Grandstream’s cloud and on-premise network management platform
- Built-in QoS allows for prioritization of network traffic
Download
Technical parameters
LAN ports
Design
On the wall, Desktop, Rackmount
Switchning capacity [Gbps]
56
Packet forwarding rate [Mpps]
41,6
Web management
Yes
Management
Web management, SSH, Telnet, Cloud (GDMS)
Features
L3, VLAN, QoS, DHCP snooping
Power type
Mains power (230V)
Fans
No
LAN speed
(8) 10/100/1000Mbps
Max. LAN ports speed
1G
PoE type
PoE-Out (only)
RJ45 ports 1G
8
SFP+ cages
2
Optical interfaces
(2) 10Gbps
PoE-Out standards
802.3af, 802.3at
PoE Out ports
8
PoE budget [W]
120
Chassis design
Metal
Power via connector/terminal
100-240 V AC~50/60 Hz
Buttons
Reset
Operating temperature [°C]
0 up to 45
Weight [kg]
2,2
Width [mm]
330
Height [mm]
44
Depth [mm]
176
Default IP address
192.168.0.254
Default login and password
admin / (preset password, see label/engraving)
