Grandstream GWN7806P Layer 2+ Managed Network PoE Switch, 48 ports / 6 SFP+
Your price incl. VAT (20.0%)
655.57 EUR
❌ The item is not available. There is no option to order.
No confirmed delivery date
6.16 EUR excl. VAT
10.25 EUR excl. VAT
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1270/Rx1330nm, 10km, 1x LC connector, DDMML-S+2733-10
13.61 EUR excl. VAT
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1330/Rx1270nm, 10KM, 1x LC connector, DDMML-S+3327-10
13.61 EUR excl. VAT
841.59 EUR excl. VAT
Product description
The GWN7806(P) is a high-performance layer 2+ managed network switch with 48 ports that allows small-to-medium enterprises to build scalable, secure, and smart business networks that are fully manageable.
Key features
- 48 Gigabit Ethernet ports and 6 Gigabit SFP+ ports
- Smart power control to support dynamic PoE/PoE+ power allocation per port for the PoE models
- Supports deployment in IPv6 and IPv4 networks
- Reliability features including fault detection, device protection, dual boot, dual system file redundancy, link aggregation, storm control and more
- ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
- Embedded controller to manage switch; GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform
- Built-in QoS allows for prioritization of network traffic
- Supports stacking (pending) for easy management of up to 16 switches in one interface while creating redundant backup between multiple devices
Technical parameters
LAN ports
Design
Desktop, Rackmount
Switchning capacity [Gbps]
216
Packet forwarding rate [Mpps]
160,7
Web management
Yes
Management
Web management, SSH, Telnet, Cloud (GDMS)
Features
VLAN, QoS, DHCP snooping, L2+
Power type
Mains power (230V)
Fans
Yes
LAN ports
48
LAN speed
(48) 10/100/1000Mbps
Max. LAN ports speed
1G
PoE type
PoE-Out (only)
SFP+ cages
6
Optical interfaces
(6) 10Gbps
PoE-Out standards
802.3af, 802.3at
PoE Out ports
48
PoE budget [W]
400
Chassis design
Metal
Power via connector/terminal
100-240 V AC~50/60 Hz
Buttons
Reset
Operating temperature [°C]
0 up to 45
Weight [kg]
5,1
Width [mm]
440
Height [mm]
44
Depth [mm]
301
Default login and password
admin / (preset password, see label/engraving)
